REVIT Custom Architectural Column Family with Sweep and Reveal – CADclip

This CADclips illustartes a custom REVIT architectural column family that has two type parameters for column width and depth and 7 instance parameters for column material, sweep material, sweep height, sweep radius, reveal height, reveal vertical dimension and reveal depth dimension.
