Correct Annotation Orientation of Sloped Details in Revit.

Ok RTC talks for both AUS and USA are in, for those who don’t know if you log in to the RTCAUS submit speaker tool you can actually see if your talk has been accepted or not for RTCAUS only.

However not sure how official this is until the actual emails of confirmation go out, but check anyway!!

A user had an interesting issue the other day, I have replicated a simple version for example.

Basically he wanted an angled detail showing the true length of the member, here is a simple layout below of the project.

Now you can see in the Elevation he has gone ahead and drawn a Detail Section View as you cannot draw sections on angles.

Now when the view generated it did two interesting things, first the changed from Vertical layout to Horizontal, and any attempts to rotate the crop box fail, you can rotate it successfully to any but 90 degrees.

However we were able to place it on a sheet and use the rotate sheet view as seen below.



Once we applied dimensions they weren’t correct orientation nor…
