This tutorial covers methods for creating a diagrid on a facade that can change densities based on scripted point attractor locations. The point attractor method creates a facade with a varied look using Revit Curtain Panel Pattern Based Families. This tutorial also illustrates how to create an exterior rendering of the mock-up facade in Revit for the Module 3 Final.
