Revit Basics Tutorial – How To Use View Range

The View Range dialog looks complicated but most of the time what you need to set is simple.

– In plan view, adjust Cut Plane and Bottom values.

– In ceiling view, adjust Cut Plane and Top values.

– Set the view depth to the same value as Bottom in plan view and Top in ceiling view.

That’s it really. For 90% users, that’s all you need to know.
