If you like your classical architecture and proportions, you will be familiar with the concept of the golden mean. Also known as the golden ratio or golden section, it has fascinated architects and artists for centuries. The golden rectangle is thought to have the most pleasing proportions of any rectangle.



When spatial planning, it may be useful to first start with a room’s ‘ideal’ proportions, before adjusting it to suit the various project’s requirements. One example of how this could be used is in healthcare where the schedule of accommodation is critical.



In this workflow, an architectural column family is created which represents a ‘real’ Revit room. It contains various instance parameters including the width and length. This allows users to easily flex the family without the fear of the room ‘breaking’ due to a missing wall. Hence, it is a quick and dirty spatial planning tool before we proceed to substituting these families for real Revit rooms and…
