QCAD 3.9.1 – A powerful CAD program for performing CAD drafting in 2d

RibbonSoft is the developer of QCAD, an uncomplicated 2D CAD system for everybody. The most updated version is 3.9.1. This CAD based software is compatible with windows, linux, unix and Mac platform.

With QCAD, the CAD users can perform computer aided drafting in two dimensions (2d).

The QCAD facilitates the users to generate different types of technical drawings like plans for buildings, interiors, mechanical parts or schemas and diagrams. The source code of the QCAD community edition is launched under the GPL (Open Source).

Modularity, extensibility and portability are some of the exclusive features of QCAD. The interface of QCAD is very user-friendly.

Given below, some exclusive features of this CAD software.

  • Layers
    • Blocks (grouping)
    • 35 CAD fonts comprised
    • Metrical and Imperial units
    • DXF input / output
    • Printing to scale
    • More than 40 construction tools
    • More than 20 modification tools
  • Construction and modification of points, lines, arcs, circles,…
