Download Sample Drawing Of Double Span Portal Frame Beam Column Haunch Valley Connection

Download sample CAD dwg drawings intended for a Double Span Portal Frame Beam Column Haunch Valley Connection. The drawing comprises of Double IPE300 profile section inclined roof beams, connected to a mid frame column ( roof valley ), HEB240 column profile section, with an endplate and a haunch bottom reinforcements.

Drawing also contains bolted connection detail, full penetration butt weld specifications, column and beam web stiffeners, moment resisting endplate connection with haunch reinforcement.

By applying easy CAD commands, the detail can be simply adjusted to accommodate with any appropriate project and save significant time. These drawings provide exact detail for creating the design of a double span steel hangar portal frame as well as other types of large span roof beam-column connections.

To download the drawing, click on the following link
