A reminder for those who already know about this, and a heads up for those who do not. Multi-View Blocks do not respect any dipslay order modifications made to the nested objects in the AutoCAD block assigned as a view block to the Multi-View Block. So if you use the DRAWORDER command to get things to look the way you want in the AutoCAD block, those changes will not show up when that block is assigned to a Multi-View Block Definition and an instance of that definition is placed in your drawing file.
For example, suppose you have a custom Space Tag that includes a an overall rectangle with a dividing line that separates the Space name from the Space number, as illustrated in the image below.
Further suppose that you often place these tags in areas where there is linework “below” the tag, and you would rather not have that show inside the outer rectangle, so that the name and number can be more easily read. You might decide to add a Wipeout to the view block to accomplish this…
