Some useful AutoCAD tips to generate a simple floor plan

In this exclusive AutoCAD video tutorial, you will learn how to generate a simple 2D floor plan in AutoCAD based on given plan and requirements.

In this video, one 1 BHK 2D plan is developed in AutoCAD.

A 2D floor plan stands for a type of diagram that demonstrates the layout of a property or space from above. It will often illustrate the walls and room layout, along with fixed installations like windows, doors, and stairs as well as furniture. 2D signifies that the floor plan is a “flat” drawing, without perspective or depth.

There is a square shape land with dimension 20 feet x 20 feet and the plan will be developed for this land.

To draw anything in AutoCAD, the following two rules should be followed :-

Rule 1 : Right hand should always remain on the mouse.

Rule 2 : Left hand should always remain on the keyboard.

Prior to start drawing in AutoCAD, units and limits should be set perfectly.

If your drawing is created with the measuring unit feet and inches, the unit should set…
