11 Tips To Create Interior Finishes In Revit

There are many ways to create interior finishes drawings in Revit. Most of them are terrible and inefficient. After years of experimentations and trying different systems, we found the best way to create finishes plan. The technique taught in this guide aims to provide a consistent strategy that can be used in plan views, elevations and even 3D views. Good luck.


Create a new wall and floor type with a thickness of about 12mm (1/2”). Call these elements INT-Finish Floor and INT-Finish Wall. You can adapt the name to match your existing standards.

Model these elements where you want to indicate a specific finish in your documents. In the case of a floor, make sure to set an offset equivalent to the element thickness so it sits over the main floor element. Also, make sure the main model elements don’t include a finish layer.
