Revit 2020 has a new feature that will please Electrical designers. Feed through lugs are now incorporated into Revit for your electrical distribution system. Previously, electrical users had to utilize workarounds to represent this situation in their designs, so this will improve the documentation process and help with the electrical design.
As part of this new feature, Revit has added a new panel schedule template, which is called “Feed Through Lugs Panel“. This panel is available in the Electrical-Default.rte and the Systems-Default.rte templates. This panel template is accessible via the Manage tab -> Settings panel -> Panel Schedule Templates.
The process to actual set up the electrical panels to utilize the above Panel Schedule is shown below.
Process
- Place the electrical panels and distribution system in the model as desired.
- For the electrical panel that will be the primary panel connected “upstream”, highlight the panel and place a checkmark next to…
