ATG Webinar on Tuesday 6/25 at 12 PM CDT- AutoCAD Annotative Text- How to Utilize Multiple Drawing Scales on One Sheet with AEC Technical Specialist Scott Mizsak.
Have you ever had two viewports on the same sheet and only wanted to show the text in just one of these viewports? If the text is on different layers, not a problem. But what happens when it is the same text, just at a different drawing scale? This webinar will walk attendees through the workflows of annotative text. From creating MT ext with annotative text properties to applying only desired drawing scales to the text. Scott will wrap the webinar up with how to hide the text at certain drawing scales and then talk about the pros and cons of annotative text.
Learning Objectives: 1. Comprehend the difference between standard and annotative text. 2. Learn how to add a drawing scale to annotative text. 3. Master the skill of hiding annotative text at certain drawing scales. 4. Understand the pros and cons of…
