ACA: Using AutoLISP to Change the Swing of all Swinging Doors

There was a request to change the “swing angle” of all of the Doors in a file to 30 degrees. Building on code I previously wrote for changing the heights of Doors a given style, I put together a command function in AutoLISP that does that. One thing to know before embarking on this particular task is that while all of the 20 built-in Door Types appear to have a SwingAngle property (I did not check all 20, so do not hold me to that), only five of those types (Single, Double, Double Opposing, Uneven and Uneven Opposing) will accept a change to that property; the other 15 types will throw an error and crash the routine. There are four additional types (Single-Dhung, Double-Dhung, Uneven-Dhung and Communicating) that are in fact swinging Doors, but for some reason were not included when the SwingAngle property was introduced. (See comments at the end of the article for more on that.) The “swing” of these types can be changed using the OpenPercent property; a value of 16…
