A Brief Overview of the Adaptive Component in Revit

Parametrically Adapted Component is used for adopting a Component to different positions in space following parametric rules. The geometry of a family in adaptive Components may be related to more than one insertion point, unlike regular Components. Based on the locations of those points, the adaptive component grows differently.


1. Choose Components Template

You can create patterned panels by using the Components Template.

2. Create Adaptive Points

A conceptual design environment uses adaptive points when designing adaptive components. A square shape already creates adaptive points. Reference points are made adaptive by incorporating them into generic adoptive families. By default, adaptive reference points have a placement point. Numbering the adaptive points will follow their order of placement.

Adaptive components result from drawing geometry using these adaptive points. Changing the order of the numbers is as simple as picking one number, changing…
