12 Tips To Understand Revit Stairs

Stairs in Revit can be a source of chaos and frustration.

It doesn’t have to be that way. This guide breaks down all the complex parts into easy to digest small bites. We promise that after reading this, everyone will be baffled by how great of a stair modeler you’ve become. Enjoy these tips.

1- UNDERSTAND ALL REVIT STAIRS DEFINITIONS

Before doing anything, you need to understand all Revit stairs definitions. Have a look a the visual legend below to make sure you get everything.

BASE AND TOP LEVELS: Stairs are based on selected levels that already exist in the project. You can add an offset on these levels if required.

DESIRED STAIR HEIGHT: Total distance between the base and the top of the stairs,…
