In this exclusive AutoCAD tutorial, you will learn how to use AutoCAD to make a complete 3D house from 2D plan.
The different types of useful AutoCAD commands are used in this tutorial which are given below :-
UN (unit command) – It manages the accuracy and display formats toward coordinates, distances and angles.
DIM (dimension style manager) – It makes several dimensions and types of dimensions with a single command. It is possible to select objects or points on objects to dimension, and then click to set the dimension line.
Rectang (create a rectangle) – It is used to form a rectangular polyline from given rectangle parameters (length, width, rotation) and type of corners (fillet, chamfer, or square).
PLINE (select poly line tool) – It is applied to produce a 2D polyline, a single object that is made of line and arc segments.
LINE (to draw line) – It is utilized to make a wide array of adjacent line segments. Every segment belongs to a line object that is editable…
