4D parametric modelling of bridges with Allplan Bridge

Allplan Bridge can be used for creating 4D parametric modelling of bridges. The software provides supports to the engineers in all stages of planning ranging from the initial concept to the execution plan.

The software contains the following exclusive features :-

Formation of model: The 3D parametric model description takes into account the road layout, bridge alignment and required cross-sections to create model configuration rapid and well organized.

Complex geometries along with double curved alignment and variable cross-sections are produced easily with alphanumeric entries and formulas.

Modelling of composite and steel bridges: While specifying the cross-section, standardised and recurring profiles like longitudinal stiffeners for steel and composite cross-sections can be simply placed parametrically. Initially, the profile is specified parametrically in a individual section or imported from the user library. The location and number of components are then specified and…
