Drafting Views have an Origin Too

Drafting views look like a blank sheet of paper we can drop your pen and start sketching in. We can but it might help to know that they do have an origin and you can end up quite from from the origin if we use an external file to sketch over (which happens a lot). I routinely encounter projects that have very large drafting views, when you know where the origin is.

The old trick to find the origin in Revit was to import/link a DWG with a crosshair at the world coordinate system origin. Linked via Origin to Origin places that DWG at the origin of the view. The PyRevit application has a handy function to place a pair of intersecting lines at the origin of a view. I find I just use that now instead. It’s about the same number of “clicks” either way.

Now, the natural question to ask is, “Does it matter?” I don’t know but if large extents are bad in model views I can reasonably infer that…
