In this episode of BIM After Dark live I will be exploring various concepts around working with meshes in Revit. With the release of Revit 2023 came some welcomed improvements to how Revit deals with meshes and I wanted to share some of what I have learned and how to take advantage of the new features.
We will talk about:
– The file types you can import and compare how they look in Revit.
– Dealing with materials (rendered and shaded) when it comes to imports.
– Modifying imported mesh files to make them easier to use in Revit.
And more…
So sit back, relax, and let’s geek out!
Links Mentioned:
Join the BIM After Dark Community Today – https://community.bimafterdark.com
CGTrader – https://www.cgtrader.com/
Blender – https://www.blender.org/
TimeStamps:
00:00 Introduction
03:00 Join the BIM After Dark Community Today
07:22 What Mesh Objects and Formats Can Revit Import?
10:25 Why I Chose to Work with .OBJ Files in Revit
15:00 Downloading and Import “Thanos” Into Revit
25:00 The Benefits of User Blender BEFORE Importing into Revit
30:00 Using Face Based Families to Control Direction and Materials of Imported Objects in Revit
37:18 Linking Meshed Files to Enscape Assets in Revit
43:00 Using a Mesh Tree to Cast Shadows in a Revit Elevation
47:00 Overview of the Process and Steps to Importing Meshes into Revit
