I’m thrilled to welcome Purvi Gandhi Irwin to the show to talk about Revit Schedules. Purvi and I will run through tips and tricks for all sorts of schedules in Revit (graphics, formatting, images, combined parameters, and more).
If this is your first time ever making a schedule in Revit or you’ve made so many you’re seeing “Grand Totals, Blank Line” in your head right now, you’ll find something useful in this session!
So sit back, relax, and let’s geek out!
Links Mentioned:
Join the BIM After Dark Community – https://community.bimafterdark.com
Purvi on Twitter – https://twitter.com/BIMchiq
Shifted Paradigm Design – https://shiftedparadigm.wixsite.com/spdesign
Download Purvi’s Schedule Handout – https://shiftedparadigm.wixsite.com/spdesign/resources
TimeStamps:
00:00 Introduction
02:24 Join the BIM After Dark Community
05:00 Introducing Purvi Gandhi Irwin
09:30 Creating a Schedule in Revit
13:50 Adding Colors to Your Schedules in Revit
14:40 Grouping Headers in Schedules for Revit
18:02 The Power of “Working” Schedules in Revit
21:08 Managing Column Width in Revit Schedules
24:00 View Templates and Schedules in Revit
28:00 Adding Rows Under Your Revit Schedule Title?!
32:30 How to Reconnect a Split Schedule in Revit
35:00 Adding Dot Symbols to Your Revit Schedules
42:23 Using Combined Parameters in Revit Schedules
45:00 Using Images in Schedules in Revit
55:00 Using Conditional Formatting in Your Revit Schedules
59:00 Favorite Revit Schedule Features that have been added…
01:07:00 Outro
